8 Examples of Rx setup
8.1 Classic setup of a single receiver
(for any analogue/digital servos)
- servo impulses are generated on servo outputs
- each output can be assigned to one of the groups from A to H
- servo outputs assigned to one group are generated at the same
time
- between two consecutive servo groups there is a delay of 2.5ms
FailSafe
Enabled
8.2 Classic setup of a single receiver (for digital servos)
FailSafe
Enabled
8.3 The second receiver as a backup (clone mode)
- monitors existing connection between the transmitter and the
receiver in "Normal" mode
- does not support telemetry (or an indication of the signal
strength)
- works in receiving direction only, it never transmits
- any number of receivers in Clone mode can be operated
simultaneously
FailSafe
Enabled
COMPLEX RADIO CONTROL SYSTEM
OutputPeriod
17 ms
OutputPeriod
Auto
OutputPeriod
17 ms (or Auto)
SerialLink
JETIBOX
SerialLink
JETIBOX
SerialLink
JETIBOX
31
EN
Rx mode
Normal
Rx mode
Normal
Rx mode
Clone
