Swing Frame ASSY (12)
Teilenr.
Hersteller-Identifi kationsnr. Bezeichnung (ENG)
12.1
SL70380300
12.2
SL70383100
12.3
IN-S51102100
12.4
KPSFID2800
12.5
CNLM10*25DS20
12.6
GB2766206-2ZC3
Foam Frame ASSY (13)
Teilenr.
Hersteller-Identifi kationsnr. Bezeichnung (ENG)
13.1
SL70380500
13.2
FS573600
13.3
B10009900
13.4
026-01PL0206-5
13.5
IT90102100
13.6
IT90102200
13.7
IF81165000
13.8
CNLM10*35DS20
13.9
YZGB7710-32*3.2N19
Safety Frame ASSY (14)
Teilenr.
Hersteller-Identifi kationsnr. Bezeichnung (ENG)
14.1
SL70380600
14.2
SL70383200
14.3
SL70383300
14.4
RL81013400
14.5
026-01PL0235-11
14.6
CGH4501300
14.7
PBG10002
14.8
M02502000
14.9
IT90122000
14.10
IF81212700
14.11
GB70M10*30DHS20
14.12
GB819M6*12DHS2
14.13
CNLM10*35*35DS20
Swing Frame
Plastic Sleeve Φ26*3*55
Aluminum Cap Φ50*Φ10.5*8
Plug 50.8*76.2
Flat Head Cap Screw M10*25
Bearing 6206-2ZC3
FOAM Frame
Bush Φ44*Φ36*Φ30*19.5
Plug Φ50.8
Grip STΦ31*Φ24*111
Aluminum Grip Cap Φ25
Aluminum Grip Ring Φ25
Nut M10
Flat Head Cap Screw M10*35
Sock et Set Screw 10-32UNF*3.2
Safety Frame
Plastic Board 1
Plastic Board 2
Connective Sleeve
Grip Φ36*Φ29*338
Plastic Sleeve
Rubber Bumper
Bush Φ38*Φ32*Φ25.4*18
Aluminum Grip Cap Φ32
Nut M10
Sock et Head Cap Screw M10*30
Cross Recessed Countersunk Head
Screw M6*12
Flat Head Cap Screw M10*35
Anz.
1
1
1
1
1
2
Anz.
1
2
1
1
1
1
1
1
2
Anz.
1
1
1
1
1
1
1
2
1
1
1
4
1
27
