Replacing the fuse
If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating.
Before replacing the fuse, unplug mains lead.
Procedure:
Step 1: Unscrew the fuse-holder with a fitting screwdriver from the housing (anti-clockwise).
Step 2: Remove the old fuse from the fuse-holder.
Step 3: Install the new fuse in the fuse-holder.
Step 4: Replace the fuse-holder in the housing and fix it.
Should you need any spare parts, please use genuine parts.
If the power supply cable of this device becomes damaged, it has to be replaced by a special power supply
cable available at your dealer.
Should you have further questions, please contact your dealer.
TECHNICAL SPECIFICATIONS
Power supply:
Power consumption:
DMX control channels:
DMX512 connection:
Sound-control:
Flash-rate:
LED type:
Number of LEDs:
Beam angle:
Dimensions (LxWxH):
Weight:
Maximum ambient temperature T
Maximum housing temperature T
Min. distance from flammable surfaces:
Min. distance to lighted object:
Fuse:
Please note: Every information is subject to change without prior notice. 19.06.2015 ©
100-240 V AC, 50/60 Hz ~
95 W
12
3-pin XLR
via built-in microphone
13 Hz
10 W QCL
7
4-18°
285 x 230 x 220 mm
3.5 kg
:
45° C
a
70° C
(steady state):
C
0.5 m
0.1 m
T 1.5 A, 250 V
26/26
00091873, Version 1.0
