Put coins of one face value in the hopper, press "START" button.
Coins of a set value will get in the stacker hopper for counted coins and the result will
be shown on the display Fig. 1-8
Coins of other face values will be ejected from the tube of not counted coins (on the right)
The counter will run 3 operating cycles and stop. Press "START" again. Repeat the pro-
cedure until there are no more coins in the hopper.
Add new coins when necessary
Insert a new bag.
Repeat 7.4 operations.
In case of one face value coins being in the hopper, repeat 7.1 operations.
8

Troubleshooting

Possible reasons of failure:
1 Incorrect setting of switches "Thickness' and "Diameter"
2 Getting into hopper of foreign objects, damaged coins or foreign ones different from
national in size, together with conditional ones.
In the first case it is necessary to choose a more exact position of the switches Thickness
or Diameter or calibrate the counter again, specifying the coin parameters.
In the first and second cases, if engine is stopped, what can be detected by a specific
sound or if the coins are not ejected from any of the tubes it is necessary to:
Stop counting (press "START/ STOP", if the motor works) and take away the stacked
coin from dividing path. To do that:
Turn the diameter handle to the maximum value and press "START/ STOP" button, the
rest coins will get into the hopper for unrecognized coins and afterwards when neces-
sary do the following:
Switch off power supplies of the counter
Open a cover closing the transport mechanism Fig.3
Open upwards unit with a belt drive by cramp, Fig.4.
Remove the coin Fig. 5
