Counting speed ..................................................................................2300 coins/minute

Feed hopper capacity .....................................................................................7000 coins

Diameter of coins ......................34mm (max) - 14mm (min) (1 3/10"(max) – 11/20"(min)

Thickness of coins ......................3.7mm (max) - 0.7mm (min) (3/20"(max) – 1/36"(min))

Capacity of counting device ...........................................................................0-9999999

Range of the set counting ....................................................................................1-9999

Power consumption ..................................................................................................70W

Voltage ......................................................................220V/50Hz (For U.S. - 110V/60Hz)

Overall dimensions: ...........................27/36/33sm (10 3/5"(L) x 14 1/5"(W) x 7 9/10"(H))

Weight .........................................................................................................12kg (26.5lb)

"ADD" - Enter sum up mode. Press " ADD " button to switch ON/OFF sum up mode. If

"ADD" indicator on the control panel is lit, sum up mode is ON.

"BAT" - Choose a batch mode (0,20,35,40,50,100,200,500,1000,5000,0):

Press "BAT" button several times depending on the desired number of coins. Use the

following buttons to correct the number:

"0"-"9" - Digital keys used for input of numerical batch values in a batch mode of count-

ing (readout of operational quantity of banknotes). Pressing any key (0-9) to automati-

cally enter batch mode.

"CLR" Clear display indications

" START/STOP " Start or stop counting. Press "START/STOP" button to start or manu-

ally stop counting operation.

"M+" stores and adds the current value of counting in the memory for the chosen coin

code. If a value is stored indicator "MEM" should light up.

Figure 2
