4.0 USING A DMX512 CONTROLLER
4.1
CHANNEL ASSIGNMENT
Note: This product have different DMX512 channel configuration
that are selected at CHnd.
DMX CHANNEL (6CH)
CHANNEL
1CH
2CH
3CH
4CH
5CH
6CH
DMX CHANNEL (7CH)
CHANNEL
1CH
2CH
3CH
4CH
5CH
6CH
7CH
VALUE FUNCTION
0 - 255 R 0 - 100%
0 - 255 G 0 - 100%
0 - 255 B 0 - 100%
0 - 255 A 0 - 100%
0 - 255 W 0 - 100%
0 - 255 U 0 - 100%
VALUE FUNCTION
0 - 255 R 0 - 100%
0 - 255 G 0 - 100%
0 - 255 B 0 - 100%
0 - 255 A 0 - 100%
0 - 255 W 0 - 100%
0 - 255 U 0 - 100%
0 - 9 Strobe off
10 - 255 Strobe Speed (1 - 20 Hz)
