DMX512 SETTINGS
3.4
Enter the ADDRESS mode to set the DMX ADDRESS.
MENU
ADDRESS
MASTER/SLAVE MODE
3.5
When the fixtures work in master mode it will send out the signal
for the slave synchronous with it. To avoid the host signal and
DMX512 signals interfere with each other, should cut off the
DMX512 signals.
NOTE: Master/Slave will only work with wired connection. Slave
Fixtures must be set to Adress 001 and 7-Channel Mode.
EDIT STATIC COLOUR
3.6
Combine RED, GREEN, BLUE, AMBER, WHITE and UV to create an
infinite range of colors (0-255).
MENU
STATIC CONTROL
DMX PERSONALITY
3.7
Use Menu CHANNEL MODE to select DMX-Personality.
MENU
CHMD
0-512
RL
R. 0-255*
...
GL
...
G. 0-255*
BL
B. 0-255*
...
AL
...
A. 0-255*
WL
W. 0-255*
...
UL
...
U. 0-255*
6 CH
7 CH
8 CH
11 CH
25
