With Laser Ranging-measuring the distance between DEEBOT and surroundings through the time difference of reflection, it can map according to the objects

Laser Module

around while DEEBOT is moving� Detection of 10 m�

TrueDetect 3D

The sensor emits infrared rays and receives the light reflected from obstacles in front of it� With Infrared Ranging-measuring the distance between DEEBOT and

Sensor

surroundings by using the Similar Triangle Method, it can identify and avoid the obstacles nearby� Detection of 0�8 m�

With Infrared Ranging-detecting the distance between the bottom of DEEBOT and ground by Infrared Sensor at the bottom, DEEBOT will not move forward

Anti-drop Sensor

when there are stairs in front (For example: White ground height greater than 55mm� Black ground height greater than 30mm�) or the identified distance exceeds

the present one, realizing the Anti-drop�

Carpet Detection

The ultrasound probe can emit ultrasonic waves with a frequency of 300KHZ� The energy of the ultrasonic waves is absorbed by the carpet� If the reflected

Sensor

energy is below the threshold, the DEEBOT recognizes the presence of the carpet�

Anti-collision

When the transmitted signal is blocked by an obstacle, the signal receiver will not be able to receive the signal� With this principle, DEEBOT will avoid obstacles

Sensor

when colliding with them�

With infrared distance measurement, DEEBOT can detect the distance between itself and objects on its right side� When there is a wall or obstacle on the right

Edge Sensor

side, DEEBOT will perform edge cleaning to avoid missing spots or collisions�

Functional Description
