4.2. BACK VIEW
••
••
••
••
••
Fig. 1b: Components on the Advance ICD 10x-160x zoom stereo microscope Rear/side view.
EQUIPMENT
20. Tripod
21. Microscope arm
22. Microscope arm locking screw
23. Stopper with locking screw
24. mains connection socket
25. Dimmer for LED lighting
26. USB power cable with A) hollow plug and B) USB plug
20
••
••
••
••
••
••
LED illumination
230V power adapter (5V/1A)
27. Power adapter (5V/1A) with fitted EU plug adapter
28. UK adapter
29. Microscope head
30. Locking screw for adapter
31. Adapter with knurled ring
32. Trinotube for camera connection
••
B
••
A
••
••
