6. CLEANING/MAINTENANCE/TRANSPORT
During long breaks, and before carrying out any maintenance and cleaning work, disconnect the power supply by
unplugging the mains plug.
Remove all interchangeable optical elements (e.g. additional objectives, eyepieces, etc.) before cleaning.
As the microscope is a precision instrument, please do not dismantle any parts, otherwise proper use can no longer be
guaranteed.
CLEANING
First, blow loose dust off the lens surfaces.
Use a soft disposable paper towel soaked in 30% to 70% pure alcohol (available from pharmacies or drugstores). Do not
apply the cleaning solution directly to the optical parts. Gently wipe the lens surface by cleaning the surface with circular
movements from the center to the edge of the lens. Apply light pressure to the optics.
ATTENTION! Do not use organic solvents (e.g. alcohol, ether, acetone, xylene or other thinners) to clean painted
parts or plastic parts!
ATTENTION! Alcohol is highly flammable.
ATTENTION! Do not apply cleaning fluid directly to the appliance to avoid damaging the electronics.
Dust cover:
When not in use, cover the microscope with the dust cover and place it in a dry and mold-free place. We recommend
storing all objectives and eyepieces in a closed container with desiccant.
Transport:
Remove all loose components and the specimen to be observed from the cross table. Please pack the microscope carefully
(if possible in the original packaging).
7. TECHNICAL DATA
•Trinocular attachment for visual observation and simultaneous camera use
• Various cameras can be connected
• 1x to 4x stereo zoom lens, magnification: 10x-160x
• 2x additional lens (doubles the magnification with eyepieces and zoom lens)
• Bright LED lighting
• Two different object plates for optimum contrast to the object
• Observation of three-dimensional objects up to a maximum object height of approx. 230 mm possible
• Dimensions (LxWxH): 330 x 148 x 620 mm / weight: 4,7kg
• Power adapter 5V/1A, a matching USB power cable with a length of 1 m and two plug adapters (EU and UK) are included in
the scope of delivery
• Solid design with heavy base
• 2 pairs of wide-field eyepieces (10x/20x) included
Eyepiece:
10x wide field eyepiece
10x wide field eyepiece
with additional 2x lens
20x wide field eyepiece
20x wide field eyepiece
with additional 2x lens
8. DISPOSAL
Do not dispose of electrical appliances with household waste! In accordance with Directive 2002/96/EC of the European
Parliament on waste electrical and electronic equipment and its transposition into German law, used electrical
appliances must be collected separately and recycled in an environmentally friendly manner.
Please observe the current legal regulations when disposing of the microscope and all accessories! Information on
proper disposal can be obtained from municipal waste disposal service providers or the Environmental Agency.
Dispose of the packaging materials according to type. Information on proper disposal can be obtained from municipal
waste disposal service providers or the Environmental Agency.
Magnification:
10 - 40x
20 - 80x
20 - 80x
40 - 160x
Field of view:
approx. 22 - 5.5 mm
approx. 11 - 2.5 mm
approx. 11 - 2.5 mm
approx. 5.5 - 1.1 mm
GB
25
