ADVANCED MENU
This menu controls the advanced parameters of the charger. To move from one parameter to another push
Activation «Change battery» > Activation «Power Supply» > Activation «Expert Curve» (> Adjusment of the
«Expert Curve» parameters)
• CHANGE BATTERY mode activation:
To activate the CHANGE BATTERY mode, select «ADVANCED MENU | Change bat: ON».
Now this mode will be accessible from the mode list.
• POWER SUPPLY mode activation:
To activate the POWER SUPPLY mode, select «ADVANCED MENU | Power Supply: ON».
Now this mode will be accessible from the mode list.
• «EXPERT» curve activation:
To activate the «RECOV» curve, select «ADVANCED MENU | Expert curve: ON». Now
this curve will be available in the charging curves list from the CHARGE mode.
• Parameters adjustment of the «Expert» curve:
If the charging curve is activated, the charging curve parameters can be adjusted (type
IU I U):
0 0
- Ucharge: Charge voltage adjustable from 12.0 to 16.0V (Step 6).
- Icharge: Charging current adjustable from 10A to 200A per 100Ah of specified
capacity (Step 5).
- Urecovery: Recovery voltage adjustable up to 30.0V.
If the value «OFF» is selected the recovery function is inactive (Step 2 and 4).
- Ufloating: Floating voltage adjustment.
If the value «OFF» is selected the floating function is inactive (Step 8).
- Trecovery: Maximum time for shorted cells recovery, adjustable from 1h to 24h
(Step 2).
- Trefresh: Time for the refreshing phase adjustable from 1h to 12h. If the value
«OFF» is selected, the refresh function is not activated (Step 7).
- T desulfat: Maximum time adjustable from 1h to 24h of the desulfation phase (Step
4).
- T ch_max: Maximum charging time (Step 6 and 7).
- T ch_min: Minimum charging time (Step 6 and 7).
- Urefresh: Maximum voltage during the cooling phase (Step 7).
- OCP (Over Charge Protection): Maximum percentage of the nominal capacity
which can be injected before the protection begins.
When charging in-situ, a «Urecovery» or «Urefresh»
too high might damage the electronics of the vehicle.
We advise NOT to adjust these settings above 15 V.
To save and validate the new settings, select «ADVANCED MENU» | save? Yes»
key
Push the to exit the «Configuration» menu.
MODE
