• Start of the charge:
To start the charge, press the START/STOP button.
1
If the AUTO-DETECT function is active, charging will start
automatically after 5 seconds if a battery is present.
During charge, your GYSFLASH indicates the percentage of progress of the
2 charging cycle and alternately the voltage, current, amps hour supplied and
the duration.
3 Press the START/STOP button to stop the charge.
Precautions :
When charging a vehicle, it is recommended to reduce the vehicle power consumption to a minimum (switch off the lights, switch
off the ignition, close the doors, etc.) in order not to disturb the charging process.
Precaution: Check the electrolyte level of any open battery. Fill it up if necessary, before starting the charge.
• Lead-acid charging curve:
1
U
T
recovery
I
Analyse Récupération
0%
Step 1 : Analysis
Analyses the state of the battery (charge level, polarity inver-
sion, wrong battery...)
Step 2 : Recovery
Recovering damaged elements after deep and prolonged
discharge.
Step 3 : Test
Sulfated battery test
Step 4 : Desulfation
Battery desulfation algorithm.
Step 5 : Charge
Fast charge at maximum current to reach 80% charge level.
16 16
GYSFLASH 102.12 HF
2 3
U U
= recovery
max max
.
T
desulfat
Test Désulfatation
10%
AUTO-DETECT
U=12.3V
4 5
I I
= charge
.
T
Charge
20%
Step 6: Absorption
Constant voltage charge to reach 100% charge level.
Step 7: Refresh (only for liquid profile)
The charger supplies an additional current to create gas that
will allow the electrolyte to be mixed and thus reconditioning
the battery cells. During this phase, the battery may produce
some water.
Step 8 : Maintenance/Floating charge
Maintains battery charge level at its maximum.
CHARGE
U=13.1V
1
12V
CHARGE
Q=6.7Ah
4
1- Battery voltage
2- Progress of the charging cycle
3- Current delivered by the charger
4- Ampere hours supplied
5- Duration
6 7
U U
= refresh
U U
= charge
T
refresh
ch
Refresh
Absorption
(si option active)
95%
80%
EN
24%
2
I=9.7A
3
24%
01h23
5
8
U U
= oating
Maintien de
charge
100%
