Command data (Write)
No Function
Byte
count
142 Write digital 6
output (DOut)
mode
168 Teach Range 4
more@turck.com • www.turck.com • 2012/06
Byte Type Description
0 uint8 DOut ID:
0x01: PNP Out 2 (Temp)
0x02: PNP Out 3 (Fault)
1 uint8 not used
2 uint8 not used
3 uint8 Switch-off delay in steps:
0x00: 0 sec ...
0xFF: 25.5 sec
4 uint8 Switch-on delay in steps:
0x00: 0 sec ...
0xFF: 25.5 sec
5 uint8 Function:
0x01: active high
0x02: active low
0 uint8 Output type (AOut oder
DOut):
0x01: AOut
1 uint8 Output Index:
0x01: AOut 1
2 uint8 Teach mode:
0x01: Teach MIN trim
0x02: Teach MAX trim
not used
HART® commands
Reply data (Read)
Byte
Byte Type Description
count
6 0 uint8 DOut ID:
0x01: PNP Out 2 (Temp)
0x02: PNP Out 3 (Fault)
1 uint8 not used
2 uint8 not used
3 uint8 Switch-off delay in steps:
0x00: 0 sec ...
0xFF: 25.5 sec
4 uint8 Switch-on delay in steps:
0x00: 0 sec ...
0xFF: 25.5 sec
5 uint8 Function:
0x01: active high
0x02: active low
4 0 uint8 Output type (AOut oder
DOut):
0x01: AOut
1 uint8 Output Index:
0x01: AOut 1
2 uint8 Teach mode:
0x01: Teach MIN trim
0x02: Teach MAX trim
3 uint8 Teach status:
0x01: Teach value saved
0x02: Teach value not
saved
(DeltaFlow too high)
