Parameter list HART® for FMX-IM-2UPLi63X
No Function
134 Read actual
device state
136 Write DOut state
141 Read digital
output (DOut)
mode
8
Command data (Write)
Byte
Byte Type Description
count
0 not used
1 0 uint8 Force DOut:
Bit 0: Force mode on/off
Bit 2: DOut 2 on/off
Bit 3: DOut 3 on/off
1 0 uint8 DOut ID:
0x01: PNP Out 2 (Temp)
0x02: PNP Out 3 (Fault)
not used
Reply data (Read)
Byte
count
8
1
6
Hans Turck GmbH & Co. KG • Tel. +49 (0) 208/4952-0 • Fax +49 (0) 208/4952-264
Byte Type Description
0...8 flag 64 Flags:
Bit 00: DeltaFlow too hich
Bit 03: Short circuit DOut 2
(Temp)
Bit 04: Short circuit DOut 3
(Fault)
Bit 05: Short circuit sensor
Bit 06: Wire break sensor
Bit 07: Wire break current
source
Bit 08: General fault (ma-
nual reset needed)
Bit 10: Software error
Bit 11: Hardware error
Bit 13: DOut 2 on
Bit 14: DOut 3 on
Bit 16: Error current active
Bit 17: AOut in force mode
Bit 18: Fault current source
or load too high
(switch-off of cur-
rent source; Power-
reset needed)
Bit 24: configurations
changed
Bit 25: DOut in force mode
Bit 32: Gap between MAX
and MIN too small
Bit 33: Flow rate above
indicating range
Bit 34: Flow rate below
indicating range
Bit 35: Flow rate above
operating range
Bit 36: Temperature above
indicating range
Bit 37: Temperature below
indicating range
Bit 38: Temperature above
operating range
Bit 39: Temperature below
operating range
0 uint8 Force DOut:
Bit 0: Force mode on/off
Bit 2: DOut 2 on/off
Bit 3: DOut 3 on/off
0 uint8 DOut ID:
0x01: PNP Out 2 (Temp)
0x02: PNP Out 3 (Fault)
1 uint8 not used
2 uint8 not used
3 uint8 Switch-off delay in steps:
0x00: 0 sec ...
0xFF: 25.5 sec
4 uint8 Switch-on delay in steps:
0x00: 0 sec ...
0xFF: 25.5 sec
5 uint8 Function:
0x01: active high
0x02: active low
