T5E SP
GB
®
S.A.S. au capital de 5 000 000 €- Z.I. Les Giranaux- BP71- 70103 Arc-Les-Gray CEDEX- RCS GRAY B 425 650 090- SIRET 425 650 090 00011- n° T.V.A CEE FR 87 425 650 090
Installation
1
55
- Drilling the tube :
48*
* :35Nm max.
T5E SP
230V-50Hz
- Assembly :
1
ACIER-STEEL-STAHL-ACERO-ACCIAIO
5
2
3
Travel limit settings:
2
- If using the travel limit setting tool, refer to the instructions delivered with the product.
- When setting the travel limit, there is a one-second delay in motor operation.
2.1 - Connect the motor to the settings switch
(ref:xxxxxx).
- This switch is specific to T5E & T5E SP motors. Do not
under any circumstances use it with another motor!
2.2 - Check the rotation direction.
Connect the switch to the mains, then press
a-If the shaft turns in the "up" direction, go to step 2.3.
b-If the axis turns in the "down" direction, invert the Brown
(2) and Black (3) wires on the motor, and repeat the test.
2.3 - Setting the travel limit setting mode
- Press simultaneously on
and
for 3 seconds. The motor rotates briefly one
way, then the other. Go to step 2.4.
2.4 - Setting the blockage stop mode
- Press on
for 3 seconds. The motor rotates briefly one way, then the other.
Go to step 2.5.
5013731A
Read carefully these instructions
before any use.
C
L1
20
D
A
ØB
C
Ø
4
L2
(mm)
(mm)
(mm)
min.
510-17 515-17
47
660
5
26
525-17 535-17 550-12
Ø4,8 x 10
2
Ø5 x 10
3
9910014
4
9910013
1
25Nm max.
Blue
PE
Brown
L
Black
N
green/yellow
a
b
:
>>
OK
>>
≥3s
≥3s
2.5 - Setting the lower travel limit
- With the T5E SP motor, there is no manual adjustment for the upper travel limit.
a- Position the motor on the desired lower stop limit using the
and
keys.
b- To memorize the lower travel limit, press
1st press for half a second without the motor rotating.
2nd press over 3 seconds, so the motor rotates briefly one
way, then the other.
2.6 - Confirm settings
A
4xØB /90°
- Press the
and
rotates one way then the other.
D
L1
L2
(mm)
(mm)
(mm)
- The settings are now complete. There is no longer any time delay in motor operation. You may now
connect the motor to the final reversing switch (§3).
4,2 673 693
Final wiring
3
- Mandatory use of a reversing switch that stops
the
and
- Possibility of wiring 3 motors maximum in paral-
1
lel on one switch.
- Be careful of the direction of rotation (§2.2)
2
Resetting the lower travel limit:
4
2
- With the T5E SP motor, there is no upper travel limit setting.
a
b
a- Position the motor on the lower stop limit set in §2.5 using the
b- Press the
key 3 times, each time for 5 seconds. After the second and third press the motor rotates briefly
one way, then the other.
c- Position the motor on the new desired lower position using the
1
2
d- To confirm the new Travel Limit position, press
3
and the second time for at least 3 seconds, so the motor rotates briefly one way, then the other.
Cancelling travel limit settings:
5
>>
- Connect the motor to the settings switch (§2.1)
- Press the
and
one way, then the other, then a few seconds later rotates in both directions.
After this operation, the motor returns to its factory settings; repeat the
>>
operations from chapter 2.
1 / 2
twice:
keys simultaneously for at least 3 seconds. The motor briefly
Blue
keys being activated simultaneously.
Brown
Black
Green/yellow
5s
5s
5s
>>
>>
+
+
6s max.
6s max.
twice, once for half a second without the motor rotating
keys simultaneously, for at least 7 seconds. The motor rotates
a
b
1/2s
≥3s
>>
+
>>
6s max.
≥3s
>>
PE
L
N
c
d
1/2s
>3s
>>
>>
+
6s max.
key.
and
keys.
>7s
>>
>>
2 / 2
