with heavy reinforcement, a slower speed may be required.
* If a slower speed is required, select a larger diameter setting than the
actual bit.
* If a faster speed is required, then select a smaller diameter setting
than the actual bit.
CHANGING BETWEEN mm and inch DISPLAY
With the motor plugged in, but not running, press and hold the Rebar
Assist Button continuously for 4 seconds. The displayed units will
change. To change back, repeat the process.
ELECTRONIC SPEED SETTINGS WITH CORRESPONDING RATED LOAD SPEEDS
Speed Setting Ø (mm)
500 mm
450 mm
400 mm
350 mm
325 mm
300 mm
275 mm
250 mm
202 mm
182 mm
172 mm
162 mm
152 mm
142 mm
127 mm
122 mm
102 mm
(* Torque reduced to protect bit)
4)MOUNTING TO A DRILLING STAND (NOT INCLUDED)
Warning: Do not attempt to mount to a rig that does not have a perfectly fitting mounting system.
This motor has 2 mounting possibilities. It can use an AGP system six-bolt mounting plate, or just use the lower
4 bolt holes, which are in a standard bolt hole pattern for attaching most types of 4-bolt mounting plates.
Use the mounting plate suitable for the drill stand you are using to mount your drill motor to your stand. (If
there is not enough clearance between the motor's electronics box and the drill stand, use the optional 40mm
GB
Rated Load rpm
220 /min
225 /min
230 /min
240 /min
253 /min
274 /min
300 /min
329 /min
407 /min
451 /min
478 /min
507 /min
525 /min
532 /min
540 /min
540 /min*
540 /min*
10
Rebar Assist Button
LED Load Indicator
Speed Setting Ø (inches)
20"
18"
16"
14"
13"
12''
11"
10''
8"
7"
6.5"
6.25"
6"
5.5"
5"
4.5"
4"
Bit Threading Button
Motor On/Off Button
Diameter Selector Buttons
Rated Load rpm
220 /min
225 /min
230 /min
240 /min
253 /min
274 /min
300 /min
329 /min
407 /min
451 /min
478 /min
507 /min
525 /min
532 /min
540 /min
540 /min*
540 /min*
