Number of safety contacts
Safety classification
Standards
Safety classification - Interlocking function
Performance Level, up to
Category
PFH value
PFD value
Safety Integrity Level (SIL), suitable for applications in
Mission time
Safety classification - Guard locking function
Performance Level, up to
Category
PFH value
PFD value
Safety Integrity Level (SIL), suitable for applications in
Mission time
Mechanical data
Interlocking principle
Mechanical life, minimum
Note (Mechanical life)
Allowed distance interlock to actuator, minimum
Allowed distance interlock to actuator, maximum
Angular misalignment between solenoid interlock and actuator,
maximum
Minimum distance devices
Holding force F
in accordance with EN ISO 14119
Zh
Holding force F
, maximum
max
Lateral force at bolt return, maximal (against locked door)
Note (Lateral force at bolt return)
Type of the fixing screws
Note (Type of the fixing screws)
2
EN ISO 13849-1
EN IEC 61508
e
4
1,00 x 10⁻⁹ /h
9,00 x 10⁻⁵
3
20 Year(s)
e
4
1,80 x 10⁻⁹ /h
1,60 x 10⁻⁴
3
20 Year(s)
bistabil
1.000.000 Operations
Davon mit Querkraft Fquer = 100 N: 100.000 Schaltspiele
1 mm
7 mm
2 °
30 mm
10.000 N
13.000 N
300 N
Gilt nicht für Flucht-, Bowdenzug- und Hilfsentriegelung
2x M6
Festigkeitsklasse min. 10.9
6-32
