6. nstall the bellows holder and Fixed-length column holder
7. Install the motherboard box
Screw M3*20 x 2
M3*20 X 2
8. Install the bellows
Note: Fix the bellows with black wire tie.
09
M3*8 x 2
M3*6 x 2
WIRING
Y2 Connector
X-axis Motor
Y1 Motor
Laser Module
Note: Incorrect connection between X-axis and Y1 motor line will lead to
abnormal movement.
ADJUSTMENT
Method to adjust the synchronous belts on both sides
If they loose, first loosen the pressing screws on both sides, then fasten the
synchronous belt, and push the pressing screws to the corner and tighten them.
EN
Y2 Motor
10
