2.2.4. Connecting the IR eye

That you are able to use the IR Remote you have to connect the included IR Eye. You should install
the IR eye that you can ai mit with the remote control. It will work in an area of 7m around, if you aim
at the IR Eye.
- Connect the IR Jack with the Output marked with IR
- Now the controller reacts on the signals given from the remote control

3. Functions and usage

3.1. Choice of a color

You can choose a color in different ways
Possibility 1:
Possibility 2:

3.2. Recall manufacturers settings (CLEAR Function)

If you or you are not able to find out in which program you are, you can recall all the
manufacturers settings like it was at the first use.To do that just push for at least 3s the Clear
button
That does:
- The WW/CW Dimmer and Master will be set back to 100%
- All Programs are reset to their common settings. (more at the point programs)
Choose a color by using the different color buttons
Now you can use the Master Dimmer to adjust the
brightness .
Use the 2 color dimmers to mix you color as you
desire. After that you can use again the master
dimmer to adjust the master brightness.
