2.2.3. Connecting the mic

The mic should be installed without anything covered, that i can record all the audio signals and use
them. That for there is a mic included in the package with connecting cable.
- Connect the jack of the mic cable with the output marked with MIC
- Now if you choose the audio programs at the controller the microphone can react according to
the sensitivity set.

2.2.4. Connecting the IR eye

That you are able to use the IR Remote you have to connect the included IR Eye. You should install
the IR eye that you can ai mit with the remote control. It will work in an area of 7m around, if you aim
at the IR Eye.
- Connect the IR Jack with the Output marked with IR
- Now the controller reacts on the signals given from the remote control

3. Functions and usage

Dimmer: use the dimmer to adjust the brightness every time.
Strobe: with this function you can strobe the connected fixture, and adjust the speed of the
flashes. To stop strobe function, please push one time the program button.
Program: push the program buttons to step through the described programs down below.
Attention. To come back to the dimming function please chose program 1, which means a full on to
the stripe. In the same way you can stop the strobe function, in pushing the programs as long as you
reach program 1.
X S P R O S I N G L E C O N T R O L
6 / 12
