4. Connecting and synchronizing more controllers

if you want to use more than one controller you can synchronize them by using the data connection.
Do it like described here:
- Connect DA + Out of the first Controller with DA+ of your second controller
- Connect DA - Out of the first Controller with DA- of your second controller
- Repeat point 1 and 2 until every controller is connected.
- Use one mic and one IR eye only for the whole network. Use the controller next to your
sound source, otherwise their can occur problems in synchronizing.
- After connecting the Master and Slave items, you have to start one time every function to save
the settings to the slaves, to synchronize them.
Attention!! The single functions could be not synchronized for the first use, they are after the first
usage of the program. So with the second activation it is synchronized.
Attention!! If you use only one controller it can need up to 3s until he stops trying the synchronization

5. Manuel set up

If you want to start the internal programs Manuel without the remote you can do that by
using the button at the side of the controller. With every push of the button the next program
is activated like described in the list before.
Attention!! In this case you can not do adjustments on fade and hold. The programs are working like
they were preset. The synchronization is still working in this case.
.

6. Technical data

Channels:
Accesories:
Measurements:
Weight:
A in total :
Connectors:
Max quantity. XS Pro
Max distance of connection
Attention!! In case that the remote controller is not working well, please check the battery of it, to solve
this problem!
X S P R O W H I T E C O N T R O L
2 (WW/CW)
1 x Mic, 1 x IR Eye
105mm x 65mm x 24mm
235g
15A
WW-, CW-, V+, V+ Terminal;
Data +, - Out Terminal, Mini Jack Mic; Mini Jack IR Eye
max 10 pcs linkabl
50m max for the whole network.
13 / 14
12/24V +, - Terminal; Data +, - In
