Function and features

• The controller
(AC1327/AC1337), both in accordance with the AS-i version 3.0), a
mini controller and an Ethernet IP interface.
• It controls the exchange of data to the sensor / actuator level
• processes the peripheral data in the integrated processor (signal pre-
processing)
• works as stand-alone controller with exchange of data to the PC
(visualisation)
• communicates with the higher control level (in the gateway mode)
(Ethernet / IP, Modbus / TCP)
Programming interface RS232C
• Baud rate 4800 to 115,200 baud
• Max. distance between controller
• Potential separation from the controller
• Programming cable E70320 for connection to PC required

Ethernet interface

• Ethernet / IP
10 Mbps and 100 Mbps
• TCP/IP - Transport Control Protocol/ Internet Protocol
• UDP - User Datagram Protocol
• IT functionality: file system, FTP server, Telnet server, HTTP server,
E-mail client
• RJ45, Twisted-Pair

Installation

Fix the controller
ground connection. The protection rating of the unit is IP20, therefore
it should be mounted in a protected location (e.g. control cabinet).
Ensure a condensation-free environment. Avoid excessive dust,
vibration and shock. The air circulation through the vents must
not be impeded.
Avoid installation in direct vicinity of frequency inverters.
10
integrates
e
onto a 35 mm rail which has an electrically safe
e
one or two
and PC: 20 m
e
power supply
e
AS-i masters
