SENSORS
Name Functional Description
With Laser Ranging-measuring the distance between DEEBOT and surroundings through the time difference of reflection, it can map
Solid-state LiDAR
according to the objects around while DEEBOT is moving� Detection of 10m�
Vibrating the diaphragm through air by human voice, it can realize Voice Recording and ask DEEBOT to complete the assigned work
Microphone
by Voice Control� Effective wake of 5m�
The sensor emits infrared rays and receives the light reflected from obstacles in front of it� With Infrared Ranging-measuring the
TrueDetect 3D Sensor distance between DEEBOT and surroundings through the time difference of reflection, it can identify and avoid the obstacles nearby�
The measurement range is 0�8m�
With AI Camera's surrounding image collection, it can realize the video recording and meanwhile assist in drawing the 3D map�
AIVI Camera
Through the interaction with the MIC, it can realize the Remote Voice Call� FOV: Vertical 112°, Horizontal 138°�
With Infrared Ranging-detecting the distance between the bottom of DEEBOT and ground by Infrared Sensor at the bottom, DEEBOT
Anti-drop Sensor will not move forward when there are stairs in front (For example: White ground height greater than 55mm� Black ground height
greater than 30mm�) or the identified distance exceeds the preset one, realizing the Anti-drop�
The ultrasound probe can emit ultrasonic waves with a frequency of 300KHZ� The energy of the ultrasonic waves is absorbed by the
Carpet Detection Sensor
carpet� If the reflected energy is below the threshold, the DEEBOT recognizes the presence of the carpet�
When the transmitted signal is blocked by an obstacle, the signal receiver will not be able to receive the signal� With this principle,
Anti-collision Sensor
DEEBOT will avoid obstacles when colliding with them�
With ToF distance measurement, DEEBOT can detect the distance between itself and objects on its right side� When there is a wall or
Edge Sensor
obstacle on the right side, DEEBOT will perform edge cleaning to avoid missing spots or collisions�
