REVERSE DOOR

Tool required: Philips screwdriver, Flat bladed screwdriver, Hexagonal spanner.
• Ensure the unit is unplugged and empty.
• To take the door off, it is necessary to tilt the unit backwards. You should rest the unit
on something solid so that it will not slip during the door reversing process.
• All parts removed must be saved to do the reinstallation of the door.
• Do not lay the unit flat as this may damage the coolant system.
• It's better that 2 people handle the unit during assembly
1. Remove two screws at rear side of top cover.
2. Remove top cover and placa it aside.
3. Unscrew top hinge and than remove door and place it on a
soft pad to avoid scratch.
4. Unscrew bottom hinge. Then remove the adjustable feal
from both side.
Note: remove this screw
if it presents.
