Ytango's anatomy
MaRiC unit (Microphone and Receiver in Canal)
The Ytango uses your own outer ear to capture
and focus sound, just as nature intended. The
microphone is placed inside the ear, to pick
up and amplify sound waves with natural and
clear quality.
Microphone opening
The microphone picks up the sound, which is
processed and amplifi ed by the Ytango.
Speaker (or receiver) opening
The processed and amplifi ed sound emits
through the speaker opening and is directed
via the soft dome towards the ear drum.
Received signal
Sound captured by
the outer ear
BTE module
Processed signal
Amplifi ed sound
MaRiC® (Microphone
and Receiver) module
English 11
