BOOT SCREEN
1.
Connection Validation logo
2. CV5200 Series - 80W
CV500 Series - 40W
3. Firmware Version
OPERATIONS SCREEN
1.
Net Power Meter
2. Port A Cartridge ID
3. Port A Tip Temperature
4. Select Port A
5. System Message Bar
6. Dual Simultaneous
Enable/Disable (Link)
7. Select Power Graph
8. Setup
9. Select Port B
SYSTEM MESSAGE BAR
•
ACTIVE
•
DISABLED
•
FAULT
1.
Ground Fault Detection
2. Failure to Load Firmware in Dual Simultaneous Mode
3. No cartridge detected
4. Over Temperature
POWER GRAPH SCREEN
1.
Power vs. Time graph
2. Cartridge ID
3. Cartridge Production Lot
Code
4. Cartridge Serial Number
5. Solder Event Counter
6. Return
All manuals and user guides at all-guides.com
SOFTWARE FEATURES
1
2
3
4
5
1
2
1
2
3
1
2
6
7
3
4
5. Non-Conforming Cartridge
6. Connection Validation
4
3
9
8
5
6
5
6
6
