Error codes:
Err10:
Replace the battery
Err11:
Data transfer error
Err14:
Calculation error
Err15:
Outside the measuring range
Err16:
Received signal too weak
Err18:
Tilt sensor calibration error
Information on maintenance and care
Clean all components with a damp cloth and do not use cleaning agents,
scouring agents and solvents. Remove the battery(ies) before storing for
longer periods. Store the device in a clean and dry place.
Calibration
The measuring device should be calibrated and tested on a regular
basis to ensure it is accurate and working properly. We recommend the
measuring device is calibrated every 1 - 2 years. If necessary, contact your
distributor or the UMAREX-LASERLINER service department.
Technical Data (Subject to technical changes without notice. 24W07)
Precision (typical)*
Measurement range
(inside)**
Laser class
Laser wavelength
Automatic switch-off
Power supply
Operating conditions
Storage conditions
Dimensions (W x H x D)
Weight
* measuring distance up to 10 m with strongly reflective target surface
and at room temperature. The measurement deviation may increase by
± 0.2 mm/m for greater distances and under unfavourable measuring
conditions such as strong sunlight or weakly reflective target surfaces.
** at max. 5000 lux
18
EN
± 1,5 mm
0,05 m - 50 m
2 / < 1 mW (EN 60825-1:2014/
A11:2021 / EN 50689-1:2021)
635 nm
30 sec laser / 3 min device
2 x 1,5V LR6 (AA)
-10°C ... 40°C, max. humidity
20 ... 85% rH, no condensation, max.
working altitude 2000 m above sea level
-20°C ... 70°C,
max. humidity 80% rH
50 x 122 x 27 mm
140 g (incl. batteries)
