1. Introduction
The SKF 1077600/SET contains the following equipment:
− 1077600 grease gun
− Extension pipe with 4 jaw hydraulic nozzle
− Snap-On high-pressure hose with 4 jaw hydraulic nozzle
− Snap-On extension pipe with cardan nozzle
− Snap-On extension pipe with hook-on coupler for lat-head grease
ittings (Ø 16 mm)
− Female and pointed nozzle
− Carrying case
2. Application
Hand operated grease gun according to DIN 1283 for loose grease
(ca. 500 cm / 17 l. oz.) or grease cartridges according to DIN 1284.
3
With the various standard accessories it is suitable for both standard
nipples (according to DIN 71412), lat-head grease ittings
(Ø 16 mm) and other non-standardised illing points.
3. Technical data
Maximum pressure
Volume/stroke
Length
Carrying case dimensions
Weight (complete)
4. Replacement parts
Designation
1077600-1
1077600-1A
1077600-2
1077600-3
TDTC 1/X
Other parts available on request.
SKF 1077600/SET
400 bar (5 800 psi)
approx. 1,5 cm 3
370 mm (14.6 in)
530 × 85 × 180 mm
(20.9 × 3.4 × 7.0 in)
2,4 kg (5.3 lb)
Description
Extension pipe with nozzle
Nozzle
Rubber piston of container
Vent plug
General toolcase without inlay, size X
(0.092 in 3 )
