Übersicht/Overview Mainboard D1567
Interne Anschlüsse und Steckplätze / Internal
connectors and slots
CPU
Pentium 4
22
PCI 1
PCI 2
21
PCI 3
PCI 4
20
19
PCI 5
PCI 6
18
CNR
Externe Anschlüsse / External connectors
A26361-D1567-Z120-5-6319
2324
AG P
17
16
15
14
1 =
Diskettenlaufwerk / Floppy disk drive
2 =
Power On LED II
3 =
Bedienfeld / Front panel
4 =
Stromversorgungsüberwachung /
Power supply control
5 =
Stromversorgung / Power supply
6 =
IDE-Laufwerke 3/4 / IDE-drives 3/4
7 =
USB E/F
1
8 =
Serial ATA2
9 =
Batterie / Battery
2
10 =
Serial ATA1
3
11 =
USB G/H
4
12 =
IDE-Laufwerke 1/2 / IDE-drives 1/2
13 =
SMB
14 =
Jumper / DIP-Switch
5
15 =
LCD-Bedienfeld / LCD front panel
16 =
6
Gehäuseüberwachung / Intrusion
17 =
Lüfter 2 / Fan 2
18 =
AUX Audio out
7
19 =
Audio-Bedienfeld / Audio front panel
20 =
S/PDIF-Anschluss / S/PDIF connector
8
21 =
AUX Audio in
9
22 =
10
Zusätzliche-Stromversorgung /
11
additional power supply
12
23 =
Serial port (COM2)
24 =
13
Lüfter 1 / Fan 1
Optionale Komponenten / Optional
components
Bedienfeld / Front panel
Power On/Off
HD-LED
Reset
SCSI LED Input
1) The same interface
2) 2pin or 3pin connector possible
2)
PowerOn LED II
1
3
Sleep LED
Message LED
Power On
LED 2)
1)
Speaker
