ENGLISH
Installation
1.To prevent hazardous situations, turn off the electrical power and make sure that no load is
connected to the batteries during installation.
2.The Charge Mate Pro Lithium must be installed in a well-ventilated environment, as high currents
will heat up the Charge Mate Pro Lithium. Preferably on a flat metal surface, with the fins vertical.
Do not install the Charge Mate Pro Lithium directly above the batteries because of possible
corrosive sulphur fumes.
3.Use the mounting template from the packaging to determine the exact location and screw holes.
4.Check the installation drawing for correct connection. Note that to keep the drawing easy to read,
the cable lengths have not been drawn in proportion to each other.
5.Install the Charge Mate Pro Lithium in the positive lead between the battery banks.
To prevent high cable inductance, resulting in reduced charge current or even shut down of the
Charge Mate Pro Lithium, make sure that all cables are as short as possible and free from
loops, and run the positive and negative cables as close as possible together.
6.Connect the negative of the battery banks to the Charge Mate Pro Lithium.
7.Optionally you can install a remote status light to the Status output and A+.
Remote switch (optional)
Optionally you can install a single pole ON-OFF-ON switch for remote operation of the Charge Mate
Pro Lithium, see installation drawing on page 2.
Remote switch functions
Switches input to 12/24 V.
ON
The battery banks are connected in parallel and bi-directional.
Switches input to 12/24 V for a short time.
PULSE
Emergency start (battery banks are connected for 30 seconds)
OFF
Switches input to Ground. The Charge Mate Pro Lithium is switched off.
Let the Switch input floating (or no switch connected).
AUTOMATIC
Default automatic mode with 40A / 90A fixed current limit.
