STEP 12: Install Aluminum Platforms
3. Insert the 6 pieces of M6*14 screw through the holes of the holders and align them with the
corresponding holes of the new aluminum platform and the sheet metal connector, screw them in and
tighten them.
4. Insert the 2 pieces of M6*8 screw through the corresponding holes of the sheet metal connector, and
screw them into the threaded holes of the new aluminum platform, and tighten them.
*
(2) M6 8 Flat
Head Screw
New Aluminum
Platform
Sheet Metal
Connector
*
(6) M6 14 Round
Head Screw
