5.2.

Table of adjustments

A - Front brake lever adjustment: Optimizes
the grip to suit the rider's needs (§5.3).
B - Clutch lever adjustment: To optimize the
grip according to the needs of the rider (§5.4).
C - Rearview mirror adjustment: Optimizes the
orientation of the rearview mirrors (§5.4).
D - Windscreen adjustment: Optimizes the
windscreen height to suit the rider's needs (§5.6).
E - Front suspension adjustment: The follow-
ing can be adjusted to adapt the response of the
suspension to the rider's preference:
- spring preload (All versions: §5.7.1.)
- rebound damper (TV 800: §5.7.2. / TV Lusso-
RC-SCS: §4.4.4.)
- compression damper (TV 800: §5.7.3. / TV
Lusso-RC-SCS: §4.4.4.)
ADJUSTMENTS
F - Rear suspension adjustment: The following
can be adjusted to adapt the response of the sus-
pension to the rider's preference:
- geometry height
- spring preload (All versions: §5.8.1.)
- rebound damping (TV 800: §5.8.2. / TV Lusso-
RC-SCS: §4.4.4.)
- compression damping (TV 800: §5.8.3. / TV
Lusso-RC-SCS: §4.4.4.)
G - Drive chain adjustment: To ensure safe and
effective transmission of power.
H - Headlight adjustment: To adjust the range
of the light beam to the geometry of the motorcy-
cle (§5.9.).
L - Automatic clutch adjustment (Turismo
Veloce SCS): To adjust the free play of the auto-
matic clutch.
