ASSEMBLY ON THE DIN TOP-HAT RAIL
blue'Log XM / XC
(1)
(2) DIN top-hat rail
(3) Open latch (position: down)
(4) Upper edge of DIN top-hat rail

WALL INSTALLATION

Insert two screws 80 mm apart into the wall. Hang the device on the screws using the
recesses on the rear side. Push the device downward and check to make sure it is
attached correctly.
To remove the device, push it up and pull it off to the front.
Distance between holes: 80 mm
mm
(5) Press the device
(6) Latch nose extended
(7) Closed latch (position: up)
