Cleaning and Maintenance of the Appliance
6.4 Removing and inserting the accessories in the
cooking chamber
Removing and inserting the telescopic pull-out rails
To remove the telescopic pull-outs from the side rails,
proceed as follows for each individual one:
• Press the two metal brackets of the slide-in rail to which
the telescopic pull-out is attached lightly together
with one hand.
• With the other hand, turn the telescopic slide slightly
upwards with its lower edge towards the cooking chamber
until the lower clamping hooks (1) detach from the rail.
• Then lift the telescopic pull-out slightly so that the upper
hooks (2) also come off the rail.
To reinsert the telescopic pull-outs, proceed as follows
for each individual one:
• Place the upper clamping hooks of the telescopic pull-out
(2) on the slide-in rail to which you want to attach it.
• Press the two metal brackets of the slide-in rail together
lightly with one hand.
• With the other hand, turn the telescopic pull-out
slightly downwards with its lower edge towards the slide-in
rack until the lower clamping hooks (1) engage on the rail.
• Make sure that the pull-out is firmly seated.
