Inserting/removing the battery pack

Inserting the battery pack
♦ Snap the battery pack 4 into the handle 2.
Removing the battery pack
♦ Press the two release buttons 3 and remove
the battery pack 4.

Checking the battery charge level

♦ Press the ON/OFF switch 5 to check the
charge level of the battery.
The status/remaining charge will be shown on
the battery charge level display 1 as follows:
RED/ORANGE/GREEN = maximum charge/
performance
RED/ORANGE = medium charge/performance
RED = low charge – charge the battery

Use

Select direction of rotation

WARNING!
► The rotation direction switch 9 may only
be used/adjusted when the appliance is at a
standstill.
♦ Select the direction of rotation by moving the
rotation direction switch 9 to the right or left.
Switching on/off
Turn on
♦ Press and hold down the safety lock-out 6.
Then press and hold the ON/OFF switch 5.
Once the machine is running, you can release
the safety lock-out 6. The LED work light 7
lights up when the ON/OFF switch 5 is
pressed lightly or fully.
This provides illumination of the work area in
poor lighting conditions.
NOTE
► Pressing the ON/OFF switch 5 lightly yields
a low speed/torque. Increasing the pressure
increases the speed/tightening torque.
PAR 12 B2
Switching off
♦ Release the ON/OFF switch 5.
CAUTION!
♦ The tightening torque actually attained must
always be checked with a torque wrench!

Attaching the adapter

♦ Push the adapter e onto the tool holder 8.

Maintenance and cleaning

WARNING! RISK OF INJURY! Always
switch the appliance off and remove
the battery before carrying out any
work on the appliance.
The appliance is maintenance-free.
■ The appliance must always be kept clean, dry
and free from oil or grease.
■ Never allow liquids to get into the appliance.
■ Use a dry cloth to clean the housing. Never use
petrol, solvents or cleansers which can damage
plastic.
■ If a lithium-ion battery is to be stored for an
extended period, the charge level should be
checked regularly. The optimum charge level is
between 50% and 80%. The optimum storage
environment is cool and dry.
NOTE
► Replacement parts that are not listed (such as
batteries, switches) can be ordered via our
Service Hotline.
