Danfoss TPOne-RF Benutzerinformation Seite 4

Installation Instructions
Speci cations
Operating Voltage
Output relay
Setting temperature range
Operating temperature range
Switch rating
Switch type
Battery lifetime
IP rating
On/o control
Chrono-proportional control
Operating mode
Construction
Pollution degree rating
Rated impulse voltage
Ball pressure test
Dimensions (mm)
Software Classi cation
Operating Frequency
Battery back up time
Maximum radio-frequency power
transmitted
ErP Class
The products represented within this document are classi ed according
to, and allow completion of, the Energy Related Product (ErP) Directive
System Package che and the ErP system data label. ErP Labelling
obligation is applicable from 26th September 2015.
ERP Class Product Function and ErP Description
TPI Room Thermostat, for use with on/o
IV output heaters
An electronic room thermostat that controls
both thermostat cycle rate and in-cycle on/
ErP
o ratio of the heater proportional to room
4
Product
temperature. TPI control strategy reduces
Class
mean water temperature, improves room
temperature control accuracy and enhances
system e ciency.
4
TPOne-RF
2.5 - 3VDC
(2x AA batteries)
-
5-35°C
0-45°C
-
-
Min. 2 years
IP20
Yes
Yes
Heating
EN 60730-2-9, EN 60730-2-7
Degree 2
-
H67 x W154 x D30
433.100-434.750 MHz
2 hours
10 dBm
RX1-S V2
230Vac, 50/60Hz
Volt Free
-
0 - 40°C
3A (1) at 230Vac
1 x SPDT Type 1B
IP30
-
-
-
4 kV
75°C
H84 x W84 x D28
A
Additional
e ciency
gain
2%
TPOne-RF
