12BOperating the Locator
Fig. 12: Rear of the Locator: the arrow
points towards the slot used to secure
the telescopic pole.
1
Fig. 13: Upper part of the telescopic pole
Fig. 14. Locator secured to the angled
part of the holder (2) of the telescopic
pole – the display is clearly visible.
26
•
To be able to hold the Locator flat against the
wall, slide the straight part of the holder (1) in-
to the slot on the rear of the Locator
2
or
•
To be able to view the display as you work,
3
slide the angled part of the holder (2) into the
slot.
•
Undo the clamp (3) on the telescopic pole.
Pull out the telescopic pole to the desired
4
length and then tighten the clamp (4).
