SolaX Power X3-EVC Installationsanleitung Seite 59

AC input connection port
Upgrade USB port
RS485 port
5
6
M4
60-70 mm
12 mm
12 mm
75-80 mm
Crimp L1, L2, L3, N and
PE wire respectively
RJ45 for CT/inveter connection
Network port
L1
L2
Insulation
L3
jacket
N
PE
