Cable test function
• The cable test function can be used to continuity test of ethernet- (UTP, FTP),
phone- and USB wires, in automatic and manual mode, as well.
• Connect one end of the wire, you wish to test, to the proper connector of the
connectors marked with "1" and the other end to the socket „8" or „9".
Manual testing
• Turn on the test mode by pushing the button „3", then push the button
„TEST" and the test starts.
• At each button pushing the following lead will be tested.
Automatic testing
• By pushing the button "14", the test starts. By pushing the button, the device
tests the leads one by one automatically
Error signal
• Disconnection – if one or more wires are diconnected, the LEDs with same
number do not light on the main unit and on the removable control unit
• Short circuit – If more wires are short-circuited, more LEDs light on the main
unit and on the removable control unit at the same time.
M
aintenance
• Note that the device is not water-, dust- and shock- resistant.
• Do not use and do not store the device at high temperatures, in places with
high humidity or flammability or in strong magnetic fields.
• Do not use rough textile or alcohol to clean the device.
• If the device is not being used for a longer time period, the battery must be
taken out.
Battery replacement (1 piece 9V battery)
If the LCD display shows „
way:
• Take the device out of the plastic holder and take off the battery holder cover.
• Take out the battery and replace it to a new one. Use alkaline batteries if
possible.
• Fix the battery holder cover and put the plastic holder back.
" the battery needs to be replaced the following
