GB MT
5. Make sure that the filter bag is not
pinched.
Assembling the motor head, p. 32
Removing the fleece filter bag
If the foil bag is also used: see Removing
the foil bag
1. Remove the motor head (12).
2. Pull the opening of the fleece filter bag
(21) from the suction connection (19).
3. Close the fleece filter bag: Pull the tab.
4. Remove the fleece filter bag (21) from
the dirt container (15).
Dispose of the fleece filter bag in an
environmentally friendly way.
5. Perform one of the following activities:
• Fitting a foil bag, p. 33
• Installing the fleece filter bag,
p. 33
• Assembling the motor head,
p. 32
Removing the foil bag
1. Removing the suction hose
Make sure that the suction connection
is closed by the closing flap.
2. Remove the motor head (12).
3. Flip the foil bag upwards.
4. Close the foil bag with a cable tie.
5. Pull the opening of the foil bag (24)
and, if applicable, the fleece filter bag
(21) from the suction connection (19).
6. Close the foil bag: Pull the closing tab
(23).
7. Carefully remove the closed foil bag
from the dirt container without dam-
aging it (15).
8. Dispose of the used foil bag in accord-
ance with the legal requirements.
9. Perform one of the following activities:
• Fitting a foil bag, p. 33
• Installing the fleece filter bag,
p. 33
34
• Assembling the motor head,
p. 32
Attaching and removing the
suction hose
Attaching the suction hose (Fig. C)
1. Open the cover (20).
2. Insert the thick end of the suction hose
(7) with the lock (35) into the suction
connection (19).
You will hear the lock click into place.
Removing the suction hose (Fig. C)
1. Press and hold the lock (35) on the
suction hose (7).
2. Pull the suction hose (7) out of the con-
nector.
3. Make sure that the cover (20) securely
closes the suction connection (19).
Fitting the suction
accessories
The following accessories can be plugged
onto the fabric suction hose (7) or onto
each other:
• Handle (33)
If the air velocity falls below 20 m/s,
secondary air can be added to the air
flow with the air control (32).
• 2 × metal suction tube (31)
If you use both suction tubes, attach
the suction tube with retaining lug (29)
second. This allows you to hook the
suction tube onto the holder (28) dur-
ing short breaks.
• Floor nozzle (26)
Fitting the Parkside System
Box
Notes
• Do not attach more than one Parkside
System Box to the appliance.
• The weight of the Parkside System Box
with contents must not exceed 15 kg.
