ETP SL21-10-I06-PS
Special precautions for STR and ETT tools
WARNING Risk of injury
Major changes in joint characteristics will affect the operator reaction force and can injure the opera-
tor.
Avoid using tightening strategies in applications outside their limitations.
►
Recommended value for Rundown Complete is 10% of target torque.
►
Country of origin
Please refer to the information on the product label.
Dimensional drawings
For information about the dimensions of a product, see the Dimensional drawings archive:
http://webbox.atlascopco.com/webbox/dimdrw
Overview
The Tensor system
The Tensor system consists of a range of tightening tools powered by brushless electric motors and differ-
ent drive units.
Motors are available in different sizes. All tools are protected from overheating of the motor. Electrical pro-
tection system is based on an earth fault circuit brake, Earth Fault Protector (EFP). The EFP senses small
current leakage (>30mA) and if leakage occurs, the drive is switched off (30ms). Changing, interfering or
tampering with the protection system voids all warranty and obligations from Atlas Copco. Trouble-shoot-
ing and re-start of the system may only be carried out by an authorized person. Check the function of the
EFP on a regular basis by pressing the trip-button. The EFP should switch off accordingly.
Technical data
Ordering No
Model
Model type
Distance center to side
Speed
Length
Torque range
Torque range
Square drive
Weight
Weight
Height
Motor power
Motor voltage
Motor voltage type
EN
© Atlas Copco Industrial Technique AB - 9839 1382 00
8433220828
ETP SL21-10-I06-PS
Pistol
mm
r/min
mm
2–10 Nm
– ft lb
in
0.85 kg
1.9 lb
mm
140 W
V
3 a.c.
Product information
