OPERATING AND ASSEMBLY MANUAL
One-time assembling of the holders on the stroller
- (Pic. I) Put the holders (1+2) for the Multiboard from below on
the rear axle of the stroller. Hereby pay attention at the arrows
which must show in driving direction and at the labelling "L" for
left and "R" for right as well in driving direction.
Push the holders (1+2) inside until they hit the brake manifold of
the TFK-stroller. If it is not a TFK stroller you need to adjust the
distance according to the breadth of the Multiboard.
-(Pic II) Now the holding bows (3) can be assembled from
above through the holders. Fix the holding bows with each two
screws (4) on the underside. You have to add the round
plastic washer, when assembling at Joggster X, because the
rear axle is a bit thinner.
The holders and the holding bows can be left on the TFK-stroller
when folding.
Assembling and using of the Multiboard
- (Pic.III) Hang up the Multiboard in the holder. You can put the
steel bar into the red buttons (5). They will lock automatically.
Before removing the MultiBoard, push the red buttons (5) to
the back.
- (Pic. IV) To take off the seat push both pins front (7) and back
(8) and then pull of the seat from the fixation. By putting on the
seat take care that the pins lock hearable. For transportation
the wheel of the Multiboard can be removed by unfasten the
screw (9).
- (Pic. V) To take off the Multiboard from the holder turn it up
from the backside until the pin 6 (like in Pic. III) is free and then
pull of pin 5 (like in Pic. III).
