5 Initial operation
Plug the mains plug of the transformer into the mains plug socket.
5.1 Operating your first train
In this example we assume that you are using a locomotive with the
address 3 (ex-factory address of a decoder).
5.1.1 Calling up a locomotive address:
During initial operation, locomotive address "L0001" is displayed.
First, enter the address of locomotive 3:
Action
In this example, the direction of travel is forward (left arrow points up).
5.1.2 Controlling a locomotive:
Use the rotary knob to control the speed and the direction of the
locomotive.
Action
Display
Press the 'locomotive' key. You can now start
to enter the new locomotive address.
The number entered is displayed. If you
entered the wrong number, you can delete
the entered digits using the '<=' key.
Press the 'locomotive' key to complete the
entry process. The direction of travel and the
speed step are displayed.
Display
A clockwise turn increases the speed step.
A counter clockwise turn decreases the
speed step ....
First Steps SET101
Explanation
Explanation
