Instructions Behnke touch display 20-2006-BS, 21-2006-BS, 50-2006-BS, 43-9566-BS
GB
Mounting
2.2.3. Using the connector, connect the display
connection cable from the above-mentioned
basic electronics to the display board.
Attention: The display connection cable must
be connected parallel to the connector.
2.2.4. Fasten the display connection cable by
closing the cable lock.
Important: Close the cable locks in parallel on
both sides at the same time, in reverse order
of opening. Check for the correct seat of the
connection cable.
