Instructions Behnke touch display 20-2006-BS, 21-2006-BS, 50-2006-BS, 43-9566-BS
GB

Mounting

Maintenance and Care
You have chosen high-quality Behnke pro-
ducts with front panels made from various
materials. All materials should be cleaned
with a suitable cleaning agent in regular,
sufficiently short intervals, depending on
the material. This prevents early ageing and
patina formation on the surface. You can find
the corresponding care instructions for sur-
faces delivered by Behnke on our homepage:
www.behnke-online.de/downloads/
pflegehinweise
Original Behnke components
Please only use Behnke components for
accessories or spare parts – this also applies
to POE injectors! This is the only way to ensure
trouble-free operation. Only install or assem-
ble the electronics in the supplied housings. If
a third-party housing or a housing other than
the one provided for mounting the electro-
nics boards is used, we cannot guarantee
functioning and approval of your Behnke door
intercom station.
Configuration
For information on configuring the door
intercom station, please refer to the instruc-
tions for the basic electronics supplied with
your touch display. The configuration of the
3.5" touch display is also described in detail
in the help section of the corresponding door
intercom station.
18
Regulations
Please observe the relevant regulations for
the installation of telecommunications and
electrical systems and the valid, current stan-
dards and rules of network technology!

1.3. Technical data

▸
Panel:
▸
Resolution:
▸ Diagonal:
▸
Touch:
▸
Temperature range:
▸
Brightness:
▸
Background
llumination:
▸
Viewing angle:
MountIng
2.
Note: Dimensioning and installation
sketches can be found at
www.behnke-online.de/bemassung
IPS panel
320x240 pixels
3.5"
Resistive
-20°C to 70°C
typ. 900cd/m^2
Auto mode, brightness
dimmable
horizontal and vertical
typically +/- 70-80°
