Exsys EX-44088 Bedienungsanleitung

EX EX- EX - - 44088 44088 44088
JUMPER SETTING & CONNECTORS
JP1:
DIS = The function PME is disable (Factory Setting)
DIS | ENA
ENA = The function PME is enable. Now the card can be activate
the computer through the serial ports.
J5:
1 +5V
For aux power (JP5), J5 must be connected to pc power supply!
2 GND
3 GND
If not, the card wont work.
4 +12V
DB 9M:
Serial 9 Pin D-SUB male connector
Pin Signal Pin
1 CDC 4
2 RXD 5 GROUND
3 TXD 6
DB62F:
Serial 62 Pin female connector
Pin Signal Pin
1 TXD 1 22
2 DTR 1 23
3 RXD 2 24
4 DSR 2 25
5 DCD 2 26
6 TXD 3 27
7 DTR 3 28
8 RXD 4 29
9 DSR 4 30
10 DCD 4 31
11 RXD 5 32
12 DSR 5 33
13 DCD 5 34
14 TXD 6 35
15 DTR 6 36
16 RXD 7 37
17 DSR 7 38
18 DCD 7 39
19 RXD 8 40
20 DSR 8 41
21 DCD 8 42
5
English English English EX- EX EX - - 44088 44088 44088
HARDWARE INSTALLATION
If you are ready with the jumper settings, please proceed with the following installation instruc-
tions. Because there are large differences between PC's, we can give you only a general installa-
tion guide for the EX-44088. Please refer to your computer's reference manual whenever in
doubt.
1. Turn off the power to your computer and any other connected peripherals.
2. Remove the mounting screws located at the rear and/or sides panels of your Computer
and gently slide the cover off.
3. Locate an available expansion slot and remove its covers from the rear panel of your
computer. Make sure it is the right expansion slot for the card (see card description)
4. Align the card with the PCI-Express slot and then gently but firmly, insert the card. Make
sure the card is seated and oriented correctly. Never insert the card by force!
5. Then connect the card with a screw to the rear panel of the computer case.
6. Gently replace your computer's cover and the mounting screws.
Signal Pin Signal
DTR 7 RTS
DRIVER INSTALLATION
8 CTS
DSR 9 RI
Windows 9x/ 2000/ XP/ Vista/ 7/ 8/ Server 20xx
After starting Windows it recognizes a new "PCI Controller" and opens the hardware assis-
tant. Please choose manual installation and put the driver CD into your CD-Rom drive. Now
enter the Path "D:\IO\SYSTEMBASE\"
"32bit_Win2000,XP,2003,Vista,2008,7,8" or "64bit_WinXP,2003,Vista,2008,7,8" into the
box for the Path/Source and click at >next/continue<. Now Windows will search for the drivers
Signal Pin Signal
in the specified directory. Follow the hardware assistant and finish the installation. If Windows
RXD 1 43 CTS 1
recognizes other new devices repeat the above described steps. Attention! Restart Windows
in any case after installing the drivers.
DSR 1 44 RTS 1
DCD 1 45 GND
CHECK THE INSTALLED DRIVER
TXD 2 46 CTS 2
Click at Start<>Run< then enter "compmgmt.msc" and click at >OK<. In the windows that
open select >Device Manager<. Under "Ports (COM and LPT)" you should find one or more
DTR 2 47 RTS 2
new "PCI Ports" as sample (Com3). If you see this or similar entries the card is installed
RXD 3 48 CTS 3
correctly.
DSR 3 49 RTS 3
CHANGE PORT NUMBER
DCD 3 50 GND
If you like to change the port number for example COM3 to COM5, open the >Device Manager<
TXD 4 51 CTS 4
click at >COM3<, >Settings< and then >Advance<. There you can change between COM3 till
DTR 4 52 RTS 4
COM256.
GND 53 CTS 5
Windows NT 4.0
TXD 5 54 RTS 5
Start Windows NT and insert the driver CD into your CD-ROM drive (for example D:). Click at
DTR 5 55 GND
>Start< >Run< and enter „D:\IO\SYSTEMBASE\WinNT\Install.exe" then click >OK<. Win-
RXD 6 56 CTS 6
dows NT will now start the setup program and install the driver. Please Restart Windows NT
DSR 6 57 RTS 6 after installing the drivers.
DCD 6 58 GND
CHECK THE INSTALLED DRIVER
TXD 7 59 CTS 7
Click at >Start< >Programs< >Administrative
Diagnostics< then click at >Resource< >IRQ<. Here you should find the entry „09
DTR 7 60 RTS 7
PCI". Then click at >I/O-Port< here you should see the entries „D400-D407 sysbase 0 PCI"
GND 61 CTS 8
„D800-D802 sysbase 0 PCI" and „DC00-DC1F sysbase 0 PCI" for the ports. The I/O
TXD 8 62 RTS 8 addresses can change depends which system and card is installed. If you see these or similar
entry's the card is installed correctly.
DTR 8
SCO UNIX / LINUX
The drivers are located in the following folder on our driver CD:
"D:\IO\SYSTEMBASE\SCO"
Because each individual distribution and kernel version of Linux is different, sadly we cant
provide a installation instruction. Please refer to the installation manual for standard IO ports
from your Unix/Linux version! In some newer versions of Linux the card will even be installed
automatically after starting Linux.
English English English
S1-S8: 62 Pin Buchse
and then the directory of your system
Die EX-44088 ist eine PCI-Express serielle RS-232 Karte mit 8 seriellen FIFO 16C95x Ports,
für den Anschluss von High-Speed seriellen RS-232 Peripherie Geräten (z.B. Terminal, Mo-
dem, Plotter usw.). Der serielle PCI-Express Bus unterstützt dabei optimal die Leistung des
schnellen SystemBase Chipset mit 256byte FIFO Cache. Die EX-44088 gewährleistet so eine
sichere Datenübertragung und exzellente Performance von bis zu 921KBaud/s für jedes
angeschlossene Gerät! Sie unterstützt alle PCI-Express Slots von x1 bis x16. Es ist nicht
möglich die I/O Adressen und Interrupts manuell einzustellen, da die Einstellungen der Karte
vom System (BIOS) und beim installieren des Betriebssystems automatisch vorgenommen
werden. Über die Jumper können Sie 12V oder 5V auf Pin 9 des seriellen Anschluss umleiten.
Achten Sie bitte darauf dass die Angeschlossenen Geräte dies auch unterstützen.
Kompatibilität:
Betriebssysteme:
Anschlüsse:
Lieferumfang:
Zertifikate:
JP4:
Tools[Common]< >Windows NT-
o 0
JP5:
6
Bedienungsanleitung Bedienungsanleitung
Vers. 1.0 / 11.06.14
AUFBAU
JP4: Power auf 9 Pin JP5: Jumper für die Stromquelle
Stecker Ein/Aus
für Octopus Kabel
mit 8 x 9 Pin
Seriell Anschluss
BESCHREIBUNG & TECHNISCHE DATEN
PCI-Express x1 bis x16
WIN NT 4.0/ 9x/ 2000/ XP/ Vista/ 7/ 8/ Server 20xx/ Linux
8x 9 Pin Seriell D-Sub Stecker
EX-44088, Treiber CD, Anleitung, Octopus Kabel
CE CE CE CE / FCC / RoHS / WEEE DE97424562 / WHQL
JUMPER EINSTELLUNG & ANSCHLÜSSE
DIS = Am Pin 9 liegt das Standard Signal RI (Ring Indicator) an.
(Werkseinstellung)
DIS | PWR
PWR = Am Pin 9 kann jetzt eine Spannung von DC5V oder DC12V
eingestellt werden.
Die Einstellung der Spannung nehmen Sie mit JP5 vor. Dieser sollte
aber bei Standard Anwendungen nicht verstellt werden.
Wenn Sie den Jumper JP4 für auf PWR gesetzt haben, können Sie mit
dem Jumper JP5 den Spannungswert einstellen. Es gibt 4 verschiedene
X5V Spannungsquellen. (Nur in Verbindung mit JP4 auf PWR!!!)
X12V
I12V
X 5V = 5Volt vom PC-Netzteil (Werkseinstellung)
X 12V = 12Volt vom PC-Netzteil
I 12V = 12Volt vom Mainboard
1
(Netzteil oder PCI-Express Bus)
J5: Stromanschluss
für PC Netzteil
SystemBase Chipset
JP1: PME
Ein- / Ausschalten
