Explanation of displays and buttons
3
4
L L N
1.
Antenna
2.
Connecting terminals
3.
Programming button
4.
Transmission pilot light
Sample wiring diagram
Caution
Risk of injury due to electric shock.
Connection may only be performed by a qualified electri-
cian!
The device only offers back-of-hand protection, not
touch protection.
Do not bend, shorten or lengthen the antenna.
Only operate the programming button with an insulated
tool.
16 - en
1
VC421-II
4034 200 267 0
Becker-Antriebe GmbH
Friedrich-Ebert-Str. 2-4
35764 Sinn / Germany
230-240 V AC / 50 Hz
0T 55
IP20
Made in Germany
2
