Warning! During operation,
this electric tool generates an
electromagnetic field which,
under certain circumstances, may
impair the functionality of active
or passive medical implants. To
reduce the risk of serious or lethal
injuries, we recommend that per-
sons with medical implants consult
their doctor and the manufacturer
of their medical implant before op-
erating the machine.
Assembly
Disconnect the plug before any
work on the equipment. There is a
risk of injury.
Assembling the Curved
Handle
For a simple installation, select cut-
ting height 25 mm (see „Adjusting
the cutting height").
(Fig. A)
1. Pull the connecting caps (3a) over the
tube ends on the lower bar (3). Slightly
bend up the lower bar (3) and attach
it with the connecting caps (3a) right
and left onto the lawn mower housing
(8).
2. Fasten the lower bar (3) using the wing
screws (11) for the bar fastening.
Select one of the 3 possible
height settings marked on the
lawn mower housing (8) and on
the connection cap (3a).
(Fig. B)
3. Thread the extension cable strain relief
(2) onto the U-handle (1).
4. Fix the U-handle (1) to the lower bar
(3) using the enclosed triangular grip
screws (24) and two quick-release le-
vers with washers (15).
5. Lock the quick-release levers (15) by
pressing them in the direction of the U-
handle (1).
They must fit the U-handle so that
tensioning can be carried out with me-
dium force.
Otherwise, the quick-release lever (15)
must be turned clockwise for tensioning
them or anticlockwise to loosen it.
6. Clip the cable holders (16) right and left
onto the lower bar (3) and U-handle (1)
and use them to fix the machine cable
(12) and Bowden cable (4) in place.
Mounting the grass
collection box
(Fig. C)
1. Clip the carrying handle (13a) into the
top of the grass collection box (13).
2. Place the plastic tabs (13c) over the
grass collection box rod (13b).
Operation
Hanging On/Removing the
Grass Bag
(Fig. D)
1. To hang on the grass bag (13), lift the
collision guard (5) and hang on the
grass bag. Fold the collision guard (5)
onto the grass bag (13). It holds the
grass bag in the correct position.
2. To remove the grass bag (13), lift the
collision guard (5) and detach the
grass bag. Fold the collision guard (5)
back onto the mower housing (8).
