Main parts
a
b
c
d
e
f
g
h
i
j
Pos.
Cabinet
Service door
Motor
Centrifugal impeller
Ventilator housing
Locking screws (supplied with screwdriver)
Mounting bars with vibration dampers
Self-tapping screws
OSGR coupling (accessory). When fitting the OGSR, the slit must always be
opposite the rivet, so that the guide plates are turned correctly.
EC control/terminal box
