CONTROL BUTTONS AND CONNECTIONS
Connections on the device
13 USB
14 CARD
15
Kopfhörer-Buchse
16 AV OUT
17 AV IN
18 OFF / ON
19 DC IN 12V
20 STATUS-ANZEIGE

REMOTE CONTROL

USB type A socket for media playback (max. 16GB / FAT32).
SD card slot for media playback (max. 16GB / FAT32).
Headphone socket 3.5mm
AV output to transfer the picture and sound signal to an external device.
AV input to display an external AV source on the DVD7002N.
Slider to switch the device on or off.
Power connection for the mains adapter to charge the integrated battery.
Battery LED: Indicates the status of the device.
IR receiver: Infrared interface for the remote control.
Power LED: Indicates whether the device is switched on or off.
